Velleman R1500A Round Metal Push Button Spst Off-(on)
General Information
Manufacturer
Velleman
Part Number
R1500A
Product Type
Metal Push Button
California Residents
Proposition 65 Warning
Specifications
Material
Silver alloy
Weight
0.02 kg
0.05 lb
Miscellaneous
Features
Type : OFF-(ON) SPST
current - voltage: -
Mounting hole : Ø 19 mm
Operating temperature : -25 °C ~ +55 °C
Relative humidity : 45~85% RH
Insulation resistance: > 100 MΩ
Contact resistance: < 50 MΩ
Contact material: silver alloy
mechanical life: 1,000,000 cycles
Electrical life: 50,000 cycles
dielectric strength:
between terminals of the same pole : 1000 VAC
between terminals of different poles : 2000 VAC
Housing material : nickel-plated brass
pressure : 5.5 N
IP protection rating : IP40/IP65
max. voltage: 24 VDC / 1 A 230 VAC / 0.5 A
current - voltage: -
Mounting hole : Ø 19 mm
Operating temperature : -25 °C ~ +55 °C
Relative humidity : 45~85% RH
Insulation resistance: > 100 MΩ
Contact resistance: < 50 MΩ
Contact material: silver alloy
mechanical life: 1,000,000 cycles
Electrical life: 50,000 cycles
dielectric strength:
between terminals of the same pole : 1000 VAC
between terminals of different poles : 2000 VAC
Housing material : nickel-plated brass
pressure : 5.5 N
IP protection rating : IP40/IP65
max. voltage: 24 VDC / 1 A 230 VAC / 0.5 A
$3.85
Original: $10.99
-65%Velleman R1500A Round Metal Push Button Spst Off-(on)—
$10.99
$3.85More Images
Velleman R1500A Round Metal Push Button Spst Off-(on)
General Information
Manufacturer
Velleman
Part Number
R1500A
Product Type
Metal Push Button
California Residents
Proposition 65 Warning
Specifications
Material
Silver alloy
Weight
0.02 kg
0.05 lb
Miscellaneous
Features
Type : OFF-(ON) SPST
current - voltage: -
Mounting hole : Ø 19 mm
Operating temperature : -25 °C ~ +55 °C
Relative humidity : 45~85% RH
Insulation resistance: > 100 MΩ
Contact resistance: < 50 MΩ
Contact material: silver alloy
mechanical life: 1,000,000 cycles
Electrical life: 50,000 cycles
dielectric strength:
between terminals of the same pole : 1000 VAC
between terminals of different poles : 2000 VAC
Housing material : nickel-plated brass
pressure : 5.5 N
IP protection rating : IP40/IP65
max. voltage: 24 VDC / 1 A 230 VAC / 0.5 A
current - voltage: -
Mounting hole : Ø 19 mm
Operating temperature : -25 °C ~ +55 °C
Relative humidity : 45~85% RH
Insulation resistance: > 100 MΩ
Contact resistance: < 50 MΩ
Contact material: silver alloy
mechanical life: 1,000,000 cycles
Electrical life: 50,000 cycles
dielectric strength:
between terminals of the same pole : 1000 VAC
between terminals of different poles : 2000 VAC
Housing material : nickel-plated brass
pressure : 5.5 N
IP protection rating : IP40/IP65
max. voltage: 24 VDC / 1 A 230 VAC / 0.5 A
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
General Information
Manufacturer
Velleman
Part Number
R1500A
Product Type
Metal Push Button
California Residents
Proposition 65 Warning
Specifications
Material
Silver alloy
Weight
0.02 kg
0.05 lb
Miscellaneous
Features
Type : OFF-(ON) SPST
current - voltage: -
Mounting hole : Ø 19 mm
Operating temperature : -25 °C ~ +55 °C
Relative humidity : 45~85% RH
Insulation resistance: > 100 MΩ
Contact resistance: < 50 MΩ
Contact material: silver alloy
mechanical life: 1,000,000 cycles
Electrical life: 50,000 cycles
dielectric strength:
between terminals of the same pole : 1000 VAC
between terminals of different poles : 2000 VAC
Housing material : nickel-plated brass
pressure : 5.5 N
IP protection rating : IP40/IP65
max. voltage: 24 VDC / 1 A 230 VAC / 0.5 A
current - voltage: -
Mounting hole : Ø 19 mm
Operating temperature : -25 °C ~ +55 °C
Relative humidity : 45~85% RH
Insulation resistance: > 100 MΩ
Contact resistance: < 50 MΩ
Contact material: silver alloy
mechanical life: 1,000,000 cycles
Electrical life: 50,000 cycles
dielectric strength:
between terminals of the same pole : 1000 VAC
between terminals of different poles : 2000 VAC
Housing material : nickel-plated brass
pressure : 5.5 N
IP protection rating : IP40/IP65
max. voltage: 24 VDC / 1 A 230 VAC / 0.5 A
